GME PSM1215 Switch Mode Power Supply (15 Amp Peak)
GME PSM1215 Switch Mode Power Supply (15 Amp Peak)
GME PSM1215, Switch Mode Power Supply (15 Amp Peak)
High-efficiency switch mode power for cooler operation and longer life.
Overview
The GME PSM1215 is part of GME's PSM Series of regulated power supplies, offering quality and superior performance. All PSM Series units feature rugged steel construction with less than 20mV ripple at continuous rating, making them ideal for RF and computer applications.
With a vented wrap-around steel cover, high-efficiency heat sinks, heavy-duty construction, and PC board mounted regulator circuitry, the PSM series delivers solid performance and high reliability.
Key Features
- 13.8V DC regulated output means stable power from a 240V AC mains input.
- 15A peak / 12A continuous current means enough power for most communication equipment.
- Compact, lightweight aluminium heat sink means efficient cooling in a smaller footprint.
- Thermally controlled in-built fan means active cooling under load.
- High-efficiency switch mode technology means cooler operation and a longer service life.
Applications
- Base station radios
- Workshop and test bench use
- RF and computer equipment power
What's in the Box
- Power supply with lead
Key Specifications
| Product Code | PSM1215 |
| Input | 240V AC, 50Hz |
| Output | 15A peak / 12A continuous, 13.8V regulated |
| Cooling | Thermally controlled in-built fan |
| Warranty | 1 year |
FAQs
What's the difference between this and the PSA range?
The PSM series uses switch mode technology for cooler running and a lighter unit, the PSA series is a linear regulated design.
